HDPE Dredging Pipes for Cutter Suction Dredger with Pipe Float

Product Description

• End: Flared Ends, No Welding
• SDR: SDR26~SDR11
• Type: Thermoplastic Pipe
• Shape: Round
• Usage: Water Supply Pipe, Dredging
• Hollow: Hollow
• Length: 5.8m, 11.5m, Customized Length
• Origin: China
• Flanges: Loose Flanges at Both Ends
• Trademark: Xincheng
• Application: Dredging, Sea Oil, Port Construction, etc.
• Specification: DN 110mm-1000mm
• Standard Size: DN110mm~DN1000mm
• Working Pressure: 0.6MPa ~ 1.5MPa
• Transport Package: in Steel Frames
• Production Capacity: 200000ton/Year

Dredging HDPE pipe is made from wear resistant HDPE mixed with anti-UV material by extrusion molding technology.HDPE pipes have exceptional properties such as corrosion resistance and light weight that makes them the best choice for dredging contractors.

HDPE Pipe Struction:
1. 100% HDPE raw material
2. Enlarged end, or flare end some people call, No welding required.
3. Nodular cast Iron inserts at end to protect it from deformation,breaking and leakage
4. Loose flang rings (carbon steel, galvanized) at both ends
5. Rubber gasket in between when two pipes are connected by bolts and nuts.

HDPE Pipe Advantages:
1. Light weight, easy for transportaion and installation.
2. Good flexibility, tensille force and strength
.3. Strong wear resistance & corrosion resistance
4. Flared ends, no welding, loose flanges at both ends.
5. Smooth inner wall, small friction coefficient
6. Enviromental friendly.
